Drum Synth Kit/Assembled
£46.80 – £67.04
Available as a kit or a fully made unit, the Rakit Drum Synth is based on the Boss PC-2/AMDEK PCK-100 percussion synthesizer. The sounds produced by the synth are not limited to what you would expect to associate with drum sounds and can vary from big bass drums to tapping on glass to UFO space drum-wobbly things! Not only does this Drum Synth do sonic justice to the original but we have also put our own spin on it with extra modifications including: * Attack on/off * VCO & LFO wave shape selection * Pitch CV input To find out more please read the full description below…
WE ARE AWAY FROM 21ST DEC TO 27TH - ALL ORDERS PLACED DURING THIS TIME WILL BE SHIPPED THEREAFTER
- Description
- Additional information
- Specifications
- KIT CONTENTS
- Customer Videos (3)
- SHIPPING
- Reviews (13)
Kit Assembly
Only two basic soldering tools are required to complete this kit: a soldering iron and a pair of flush cutters. Lead free solder is included! We are unable to provide individual customer support with kit building so please see our detailed assembly guide here to gauge difficulty. Once started, kits cannot be refunded.
The kit is made entirely of interlocking PCBs and unlike most kits the only wires that have to be soldered are the ones going to the piezo disc.
How it Works
The synth is triggered by a piezo disc which is sensitive to how hard you tap the top panel giving subtle differences in the envelope. The sounds are generated by a VCO optionally modulated by a frequency sweep, LFO, Pitch CV or all three.
There is a simple envelope generator with a fixed fast attack for punchy percussive envelopes and variable decay for super short to really long decays (5 seconds+).
Buy it Made
Don’t want to make the kit? No problem! The Drum Synth is also available to buy completely assembled and ready to go.
Extra Fun
An example sheet is available to download at the end of the assembly guide showing you how to recreate 8 settings from the original Boss PC-2/AMDEK PCK-100 percussion synthesizer and a blank settings sheet for recording your own favourite settings.
2x Trigger options
External Trigger
Use the 3.5mm mono socket to connect to the Rakit Baby8 Sequencer, external drum pads or anything with a gate out.
Applying an external rising edge between 500mV to supply activates the drum.
Touch Pad Trigger
Activate the piezo fixed to the underside of the top panel using a finger or weapon of your choice! We rather like the suggestion from Csaba Nagy to use a pencil with a rubber on the end. ………………………
what’s included in the drum kit
3x 3.5mm Mono Socket
4x A100k Log Potentiometer
1x B504 500k Linear Potentiometer
1x B102 1k0 Linear Potentiometer
2x 50k Trim potentiometer
1x 2.1mm/5.5mm Barrel Power Socket
2x Right Angle SPST Slide Switch
3x Horizontal DPDT Slide Switch
4x 1n0 Box Capacitor
1x 3n3 Box Capacitor
1x 22n Box Capacitor
3x 47n Box Capacitor
11x 100k 0.6W 1% Resistor
2x 33k 0.6W 1% Resistor
11x 47k 0.6W 1% Resistor
4x 22k 0.6W 1% Resistor
5x 10k 0.6W 1% Resistor
4x 4k7 0.6W 1% Resistor
1x 390R 0.6W 1% Resistor
1x 4M7 0.6W 1% Resistor
5x 1k0 0.6W 1% Resistor
1x 56k 0.6W 1% Resistor
1x 1M0 0.6W 1% Resistor
1x 220k 0.6W 1% Resistor
1x OTA IC BA6110
1x Op Amp 4558 IC
3x Op Amp 358/2904 IC
2x 3mm Blue LED
3x Signal Diode 1N4148
1x Schottky diode IN5819
2x 2N3904 NPN Transistor
2x 2N3906 PNP Transistor
2x 2SC945P NPN Transistor
3x 1u0 Electrolytic Capacitor
2x 10u Electrolytic Capacitor
1x 100u Electrolytic Capacitor
4x PCB – Top, Inside, Left and Right
1x Battery Snap to Barrel
4x Rubber Tube
the boring bit (returns policy)
| Weight | 202 g |
|---|---|
| Dimensions | 140 × 100 × 22 mm |
| Kit/Assembled | Kit, Fully Assembled |
| Add Battery + £2.49 | Yes, No |
Specifications
| Power Source: | 9v battery(PP3) with barrel jack adapter (supplied) or +8 to +12V adapter [2.1mm centre (+) 5.5mm outside (-)] |
| Power Consumption: | 10mA |
| CV Input Range: | 0V to Supply, (Pitch control works as a bias) |
| Trigger: | 500mV to Supply, (Very Sensitive, sensitivity control works on all trigger inputs to adjust response) |
| VCO Range: | 30Hz to 3.5kHz |
| LFO Range: | 2 to 400Hz |
| Decay Time: | 50ms-5s+ |
| Output Level: | ~1.2Vpp Max, adjustable with volume trimmer (varies with supply voltage) |
| Outside Dimensions: | 73 (W) x 38 (H) x 100 (D) mm |
KIT CONTENTS
Customer Videos (3)
SHIPPING
*BREXIT UPDATE*
We do not charge VAT so if ordering from Europe you may need to pay this fee when your order arrives. If you prefer to pre-pay your tax at point of purchase and clear customs quicker, please use our Etsy store.
